AM6601 Audio Decoder 7.1-Channel Home Theater - 翻译中...

Características

● 5-inch 65.5K-pixel color LCD display with full-touch menu operation; supports both Chinese and English interfaces with a simple and intuitive UI.
● Equipped with 4 HDMI audio/video inputs and 2 HDMI outputs; supports both optical and coaxial digital audio inputs.
● Fully supports DOLBY and DTS 7.1-channel cinema decoding with 7.1-channel balanced output; features 16-band parametric EQ for music and independent 16-band parametric EQ for microphone A/B channels.
● Professional-grade KTV reverb effects; echo and reverb each support independent 3-band EQ adjustment; 4-level microphone feedback suppression ensures worry-free anti-howling performance.
● Main output, center, subwoofer, surround, and rear channels each feature 5-band parametric EQ (PEQ), electronic crossover, input selection and mixing ratio, polarity, delay, limiter, and gain control functions.
● Powered by an ADI DSP chip with a 400MHz main frequency and 48kHz sampling rate, supporting 32-bit floating-point processing.
● Uses high-performance 24-bit A/D and D/A converters for excellent audio quality.
● Supplied with professional PC software; supports USB, RS232, LAN, and WiFi communication connections.
● Supports RS232 and RS485 central control functions, allowing external devices to send control commands to the unit.
● Supports saving and recalling up to 10 preset modes.
● Features 2-level device lock functions, allowing users to set lock levels as required.
● Dedicated recording output function.

Entre em contato agora Deixe mensagem

Introdução
Especificação

翻译中...

Model	AM6601
Output Channel	Main(R/L) / Center / SUB / SURR(L/R)
SNR	Microphone	＞85dB
SNR	Music	＞100dB
Distortion	Microphone	＜0.01%
Distortion	Music	＜0.01%
Max. Input Level	Microphone	250mV
Max. Input Level	Music	2V
Max. Output Level	Microphone	3Vrms
Max. Output Level	Music	3Vrms
Sensitivity	Microphone	15mV
Sensitivity	Music	300mV
Input Impedance	Microphone	10KΩ Balanced
Input Impedance	Music	47KΩ Unbalanced
Output Impedance	300Ω Balanced, 1KΩ Unbalanced
Channel Separation	＞85dB
Feedback Suppression Function	4-Level Feedback Suppression Setting
Channel Parameters	Microphone / Music	16-band PEQ + Low-pass + High-pass Gain: -20dB ~ +10dB
Channel Parameters	Output	Output: Signal Mixing + Polarity + 5-band PEQ + Low-pass + High-pass + Limiter + Delay + Gain
Decoding Formats	Dolby AC-3, Dolby Digital, Dolby Pro Logic, DTS, DTS 96/24
Net Weight	4.6kg
Package Dimensions	560×310×130mm
